Automatic Soil Compactor with Digital Blow Counter without Moulds Manufacturer,Supplier and Exporter in China
Product Code : EL-CELE-12936
Quick answer: The Automatic Soil Compactor with Digital Blow Counter without Moulds is manufactured by Science Lab Supplies, a China-based exporter of civil engineering lab equipment and construction materials testing apparatus, and forms part of the Civil Engineering Lab Equipment catalogue used by engineering colleges and construction testing labs in civil engineering and construction materials laboratories. Purpose: The time and effort required to prepare specimens for compaction studies and other test methods can often be costly and time consuming.
Purpose:
The time and effort required to prepare specimens for compaction studies and other test methods can often be costly and time consuming. The Tesca Compactor automatically compacts soil specimens, thereby eliminating the laborious hand compaction method. The height and weight of the hammer is adjustable to suit test requirements.
Salient Features:
- With electric height adjuster and digital counter
- Pre-set blow pattern ensures even compaction
- Solid state controls for reliability and ease of maintenance
- Automatic counter reset after completion of blow pattern
- An automatic blow pattern ensures optimum compaction for each layer of soil.
- The hammer itself travels across the mold and the table rotates the mold in equal steps on a base that is extremely stable.
- The number of blows per layer can be set at the beginning of the test by means of the simple digital counter system.
- Hammer, Circular faced, 2.0" (50.8 mm) diameter - foot adjustable to either 2.6 kg or 4.89 kg weight.
- Drop Adjustable to either 305 mm or 457 mm
- Controls Digital counter system, selector switch for either standard proctor test or modified proctor/CBR testing.
- Safety features like safety lever for preventing rammer falling, when the door is open, total cover for moving parts, M.C.B. for overload protection will be inclusive.
- Supplied without moulds.
Overall Dimensions : 330 X 560 X 1570 (L X W X D) mm
Related Products
See also Soil Permeability - Constant And Variable Head Test, Ball Release for Impact Resistance of Tiles - (By Measurement of Coefficient of Restitute), Triaxial Cell - 38mm Dia For Triaxial Shear Apparatus from the same Civil Engineering Lab Equipment range.
Exact technical specifications, materials and certifications should be confirmed with our team before ordering. Models are updated from time to time, so please contact us for the current product datasheet.
