Box Compression Strength Tester 1000 X 1000mm Manufacturer,Supplier and Exporter in China
Product Code : EL-MELE-12905
Quick answer: Salient Features No Calculations Required Auto?stop upon completion of Test Unlimited programmable memories Continuous rate of Loading Stepper Motor controlled operation 2/4 load cells for highest accuracy Selectable compression units N/Kgf/KN RS?232 data output facility PC Software (See optional accessories) Reputed make electric motor and its drive Digital Electro ? mechanical model. Digital Model with Backlit LCD Display for easy readability Direct Display of Load / Collapsing Force & Deflection/Compression Supplied complete with calibration certificate of Load cell traceable to National Standards Also, supplied complete with instruction manual and IQ/OQ/PQ Documents (For pharma industries) Testing Principle: Constant Rate of Loading With non?destructive testing facility for cartons at predetermined load.
Salient Features
- No Calculations Required
- Auto?stop upon completion of Test
- Unlimited programmable memories
- Continuous rate of Loading
- Stepper Motor controlled operation
- 2/4 load cells for highest accuracy
- Selectable compression units N/Kgf/KN
- RS?232 data output facility
- PC Software (See optional accessories)
- Reputed make electric motor and its drive
- Digital Electro ? mechanical model.
- Digital Model with Backlit LCD Display for easy readability
- Direct Display of Load / Collapsing Force & Deflection/Compression
- Supplied complete with calibration certificate of Load cell traceable to National Standards
- Also, supplied complete with instruction manual and IQ/OQ/PQ Documents (For pharma industries)
Testing Principle:
Constant Rate of Loading With non?destructive testing facility for cartons at predetermined load. Unlimited programmable memories
Utilities Required (To be supplied by the buyer):
Power Supply : 440 Volts, 50 Hz, 3?Phase AC Supply (Fluctuation Free Power required)
100 Kg Cast Iron Weights (In any combination. Preferably, 20kg x 5 nos). These weights are required for calibration at the time of installation and then every 6?months for routine calibrations.
|
Technical Specification |
|
|
Loading Capacity |
1000 Kgf |
|
Least count |
20 Grams (0.02 Kg) |
|
Display |
Touch screen HMI |
|
Controlling System |
PLC (Programmable Logic Controller) |
|
Suitable for a Testing Range |
10-1000 Kgf |
|
Auto Calibration facility |
At 100 Kgf |
|
Machine Platform Size |
1000 X 1000 mm (Approximately) |
|
Speed Range |
0.01 - 70 mm/min |
|
Operating Speed |
10 ± 3 mm/min (As per standard) |
|
Can accommodate Max Carton |
950 x 950 x 950 mm (H) can be accommodated |
|
Unit Selection |
N / Kgf / KN |
|
Power Supply |
440 Volts, 50 Hz, 3 Phase AC Supply |
