Broadband Signal Source Manufacturer,Supplier and Exporter in China
Product Code : EL-TAME-13146
Quick answer: Science Lab Supplies manufactures and exports the Broadband Signal Source as part of its Test and Measurement Equipment range, supplying test and measurement instruments for engineering laboratories to engineering colleges and technical institutes across engineering departments. Every unit is built for regular use in engineering test and measurement laboratories and is export-packed for international shipment from our Jining City, Shandong Province facility.
Features:
·
DC
to 6GHz Frequency range
·
Max
power: +27dBm
·
±1
dB accuracy
·
Custom
A
Description:
The Fix Attenuator operates from DC to 6GHz frequency range. It provides 3dB to
30 dB attenuation.. The same features that make the good choice for a lab.
Applications:
·
Microwave
radio & very small Aperture terminals (VSATs)
·
Cellular
infrastructure
·
Test
equipment & sensors
·
IF
& RF designs
Optional
Accessories:
·
SMA(M)
to SMA(M) 50 Ohms cable as per user requirement (Figure. 1)
·
SMA
Adaptor Kit
·
Attenuator
Kit (Figure. 2)
Electrical
Specifications:
·
Frequency
Range:
DC to 6 GHz
·
Attenuation
Flatness :
3dB ± 0.5 dB
·
Input
Power:
+27dBm (Max.)
·
Return
Loss : -14 dB Min
@ 3dB
·
In
/ Out Impedance:
Typical 50 Ohm
·
Operating
temperature:
0 ?C to 50 ?C In / Out Connector: SMMinA (F)
Mechanical
Specifications:
·
Shape:Cylindrical Shape
·
Weight:70 gm
Related Products
Exact technical specifications, materials and certifications should be confirmed with our team before ordering. Models are updated from time to time, so please contact us for the current product datasheet.
