CNC Turning Center Manufacturer,Supplier and Exporter in China
Product Code : EL-MELE-12970
Quick answer: The CNC Turning Center is manufactured by Science Lab Supplies, a China-based exporter of mechanical engineering lab equipment and trainer kits, and forms part of the Mechanical Engineering Lab Equipment catalogue used by engineering colleges and polytechnics in mechanical engineering laboratories. CNC Turning Centre Lathe with Industrial control, Electrical Control Box, Central Automatic Lubrication System, LM Guides for X & Z Axes, 8 Station Programmable Turret, Flood Coolant System, 3 Jaw Chuck The turning center is a 2 axis production machine with 8 station programmable turret and is offered with BTP63 turret.
CNC Turning Centre Lathe with Industrial control, Electrical Control Box, Central Automatic Lubrication System, LM Guides for X & Z Axes, 8 Station Programmable Turret, Flood Coolant System, 3 Jaw Chuck
- The turning center is a 2 axis production machine with 8 station programmable turret and is offered with BTP63 turret.
- The machine is built on casted base and bed and offered with industrial CNC control system. Dynamically calibrated cartridge spindle, Hydraulic Chuck and tailstock with integrated base are ideally suited for industrial production.
- The machine can be offered with FANUC / SIEMENS CNC control system.
- The 54008 can be integrated into FMS and CIM systems.
Objective
Understand the concept, components of advanced industrial machine and learn about the advanced Fanuc/Siemens/Syntec controller handling & programming skills for a turning machine to produce different kinds of components with optimized cycles and execute different kinds of practical applications simulated as exercises.
Learning Objectives:
Having successfully completed this lab, the student will demonstrate knowledge in –
- Learn about techniques to optimize the cutting parameters
- Advanced programming techniques matching industrial standards.
- Advanced machining cycles & control techniques.
- Knowledge on centralized Lubrication and re-circulating coolant system
- Learn about Intricate Tool changers system.
- Maintenance of CNC machineries and Trouble shooting
|
SPECIFICATIONS |
||
|
Axes |
||
|
X- axis travel |
mm |
120 |
|
Z - axis Travel |
mm |
320 |
|
Programmable feed rate |
mm/min |
0-10000 |
|
Rapid feed rate |
mm/min |
30000 |
|
Axis motor X / Z Type |
|
AC SERVO MOTOR |
|
Slides |
|
Linear Motion Guide ways |
|
CAPACITY |
||
|
Chuck size (Manual/ Hydraulic) |
mm |
135 |
|
Chuck Type |
|
Hydraulic |
|
Maximum turning Diameter |
mm |
200 |
|
Maximum turning Length |
mm |
300 |
|
Bed |
type |
45 deg Slant bed |
|
No. of axes |
no |
2 |
|
Swing over cross slide |
mm |
126 |
|
Distance between centers |
mm |
380 |
|
ACCURACY |
||
|
Positioning Accuracy |
mm |
0.01 |
|
Repeatability |
