CNC Turning Center Chuck size - 200 mm Manufacturer,Supplier and Exporter in China
.jpg)
Product Code : EL-MELE-12972
CNC Turning Centre Lathe with Industrial control, Electrical Control Box, Central Automatic Lubrication System, LM Guides for X & Z Axes, 8 Station Programmable Turret, Flood Coolant System, hydraulic Chuck, hydraulic tailstock
- The turning center is a 2 axis production machine with 8 station programmable turret.
- The machine is built on grey cast iron base with integrated coolant tank.
- It is offered with industrial CNC control system, Siemens/ Fanuc
- Other features include dynamically calibrated cartridge spindle, hydraulic Chuck and manual tailstock, removable chip tray.
- It comes automatic lubrication system and adjustable flood coolant system
Objective
Understand the concept, components of advanced industrial machine and learn about the advanced Fanuc/Siemens/Syntec controller handling & programming skills for a turning machine to produce different kinds of components with optimized cycles and execute different kinds of practical applications simulated as exercises.
Learning Objectives:
Having successfully completed this lab, the student will demonstrate knowledge in –
- Learn about techniques to optimize the cutting parameters
- Advanced programming techniques matching industrial standards.
- Advanced machining cycles & control techniques.
- Knowledge on centralized Lubrication and re-circulating coolant system
- Learn about Intricate Tool changers system.
- Maintenance of CNC machineries and Trouble shooting
Training Skills –
- Convenient operation and Learn about advanced programming
- Identification of the Components of the CNC System
- User friendly and graphically assisted different canned cycles
- Discussion on Programming Elements
- Discussion on Industry Standard ISO G and M Codes
- Discussion on Various Tools to be used in a CNC Turning Operation
- Study on Process Planning
- Discussion on Program Zero and Offset definition
- Preparation of CNC Programs using CNC Turning Machines
- Discussion on Various Machining Cycles used in CNC Turning Programming
- General Maintenance
|
SPECIFICATIONS |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Axes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
X- axis travel |
mm |
180 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Z - axis Travel |
mm |
320 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Programmable feed rate |
mm/min |
0-10000 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Rapid feed rate |
mm/min |
30000 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Axis motor X / Z Type |
|
AC SERVO MOTOR |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Slides |
|
Linear Motion Guide ways |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
CAPACITY |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Chuck size (Manual/ Hydraulic) |
mm |
200 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Chuck Type |
|
Hydraulic |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Maximum turning Diameter |
mm |
300 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Maximum turning Length |
mm |
280 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Bed |
type |
45 deg Slant bed |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
No. of axes |
no |
2 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Swing over cross slide |
mm |
410 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Distance between centers |
mm |
410 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
ACCURACY |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Positioning Accuracy |
mm |
0.01 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Repeatability |
mm |
±0.005 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
SPINDLE |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
{
