Digital Step Attenuator Manufacturer,Supplier and Exporter in China
Product Code : EL-TAME-13147
Quick answer: Features: · High Attenuation Range 0.25dB · Low Insertion Loss · Step error less than ±0.1dB · High Linearity · Long Battery Life · Economical · Small & Rigid design Description: The battery operated Digital Step Attenuator which operates from 100 MHz to 6.0 GHz frequency range. It provides 0.25dB attenuation with different step size.
Features:
·
High
Attenuation Range 0.25dB
·
Low
Insertion Loss
·
Step
error less than ±0.1dB
·
High
Linearity
·
Long
Battery Life
·
Economical
·
Small
& Rigid design
Description:
The battery operated Digital Step Attenuator which operates from 100 MHz to 6.0
GHz frequency range. It provides 0.25dB attenuation with different step size.
The signal output uses an SMA female connector to felicitate the connection to
RF test equipment. Its laboratory quality specifications will meet most
engineering laboratory requirements. The same features that make the good
choice for an engineering Lab.
Applications:
·
Microwave
radio & very small aperture
·
Terminals
(VSATs)
·
Cellular
infrastructure Test
·
equipment
& sensors
·
IF
& RF designs
Standard
Accessories:
·
USB
Charger (5V / 2A)
·
SMA(M)
to SMA(M) 50 Ohms cable 10”
Electrical
Specification:
·
Frequency
Range: 100 MHz to 6.0 GHz
·
Attenuation
Range: 0.25dB(±1dB)
·
Step
Size(X)(dB):0.25
·
In
/ Out Impedance: 50 Ohm
·
Input
Power: +20dBm (Max) / 0 VDC (Max)
Insertion
Loss:
·
0.1GHz
– 1GHz : 1.1 dB (Typ.)
·
1
GHz – 2GHz : 1.3 dB (Typ.)
·
2
GHz – 4GHz : 1.6 dB (Typ.)
·
4
GHz – 6GHz : 2.0 dB (Typ.)
·
Return
Loss : ≥-15dB
·
OLED
Display : 27.0 X 11.5 mm (128 X 32)
·
Operating
Temperature: 0 ?C to 50 ?C
·
Battery
Operation: 8 Hour for single charge
·
Input
/ Output Connector:SMA (F)
·
Input
Supply: 5V/2A
·
Power
Consumption: 0.49 Watt (Max.)
Mechanical
Specification:
·
Shape:
T shape
·
Weight:
430gm
