Hydraulic C Arm OT Table Manufacturer,Supplier and Exporter in China
Product Code : EL-HF-16590
Quick answer: · Radio translucent top in four sections for use of C arm image intensifier. · Compatible for orthopedic attachments. · Heavy duty smooth gear mechanism to avail all operating positions. · Durable heavy duty leak proof hydraulic pump with four pillars. · Eccentric top and hydraulic chamber adjusted at one side of base for maximum use of C ARM image intensifier. · Changeable oil valve for up & down movement of hydraulic pump. · Inter changeable head and leg section. · One radio translucent hand board and one hand rest with S.S. top for transfusion. Technical Specification · Overall length of table top:1950mm. · Overall width of table top: -500mm. · Up-down movement 770 to 1020mm. · Kidney Section Up: - 150mm. · Trendelenburg position: - 250. · Trendelenburg & Reverse position: - 250. · Lateral tilt - 200 (Both sides). · Flex/Reflex position 300/2200. · Leg section - 90 o down manual.
·
Radio
translucent top in four sections for use of C arm image intensifier.
·
Compatible
for orthopedic attachments.
·
Heavy
duty smooth gear mechanism to avail all operating positions.
·
Durable
heavy duty leak proof hydraulic pump with four pillars.
·
Eccentric
top and hydraulic chamber adjusted at one side of base for maximum use of C ARM
image intensifier.
·
Changeable
oil valve for up & down movement of hydraulic pump.
·
Inter
changeable head and leg section.
·
One
radio translucent hand board and one hand rest with S.S. top for transfusion.
Technical Specification
·
Overall
length of table top:1950mm.
·
Overall
width of table top: -500mm.
·
Up-down
movement 770 to 1020mm.
·
Kidney
Section Up: - 150mm.
·
Trendelenburg
position: - 250.
·
Trendelenburg
& Reverse position: - 250.
·
Lateral
tilt - 200 (Both sides).
·
Flex/Reflex
position 300/2200.
·
Leg
section - 90 o down manual.
Standard Accessories
·
Anaesthetic
screen.
·
Shoulder
supports with pads.
·
Arm
boards with pads.
·
Side
support with pads.
·
Black
rubberized mattress.
