Logic Probe Manufacturer,Supplier and Exporter in China

Logic Probe

Product Code : EL-TAME-16852

Common Specifications

1. Input impedance 1ΜΩ

2. Width of min. pulse: 30ns

3. Max. Input frequency: 17MHz

4. Measurable logic gate

(1) Logic 1 (red LED lights) :

TTL: 2.3V ±0.2V

CMOS: 70%Vcc

(2) Logic 0 (green LED lights):

TTL: 0.8V ±0.2V

CMOS: 30%Vcc

5. Input overvoltage protection: ±220V DC/AC 15sec

6. Pulse (yellow LED) flashing time: 500ms

7. Power supply protection: ±20V
