Current Balance (BIL Coil) Manufacturer,Supplier and Exporter in China
.jpg)
Product Code : SCL-E-11391
Science Lab Supplies is a leading Current Balance (BIL Coil) Lab Equipment Manufacturer,and suppliers in China, Current Balance (BIL Coil) Lab Equipment Manufacturer,and suppliers in South Africa.Current Balance (BIL Coil) Lab Equipment Suppliers in Mozambique,Current Balance (BIL Coil) in Supplier Kenya, Southren African region, Botswana, Lesotho, Malawi, Angola, Namibia, Zambia, Zimbabwe. Djibouti, Ethiopia, Kenya, Madagascar, Mauritius, Rwanda, Seychelles, Tanzania and Uganda.
The apparatus can be used to measure the force on a current carrying conductor in a magnetic field.
This current balance apparatus Scince Lab Supplies (BIL coil) consists of a printed circuit board coil mounted on a support handle.
The board has 2 coils – one with 5 turns and one with 10 turns, rated at 2A.
When connected to a low voltage power supply and ammeter, the balance will be deflected and the new reading can be taken.
The force on a current carrying conductor and field strength can then be calculated.
A permanent magnet should be placed on the pan of a digital balance and the BIL coil mounted in a vertical plane between the magnets.
