Power Electronics & Motor Control Experimental System Manufacturer,Supplier and Exporter in China
Product Code : EL-GLE-12196
Quick answer: The system can fulfill the lab exercises as follow: 1. Power electronics technology (1) Unijunction transistor firing circuit (2) Sine wave synchronous phase-shift firing circuit (3) Saw-tooth wave synchronous phase-shift firing circuit (4) Siemens TCA785 (5) Single-phase half wave controlled rectification (6) Single-phase half-controlled rectification bridge (7) Single-phase full-controlled rectification/ inversion bridge (8) 3-phase half wave controlled rectification (9) 3-phase half-controlled rectification bridge (10) 3-phase half wave active inversion (11) 3-phase full-controlled rectification/ Inversion Bridge (12) Single-phase AC voltage control (13) 3-phase AC voltage control (14) DC chopper circuits (15) Thyristor(SCR)characteristics (16) Gate-Turn-off Thyristor(GTO)characteristics (17) Power MOSFET characteristics (18) Giant transistor(GTR) characteristics (19) Insulated-gate bipolar transistor(IGBT)characteristics 2.
The system can fulfill the lab exercises as follow:
1. Power electronics technology
(1) Unijunction transistor firing circuit
(2) Sine wave synchronous phase-shift firing circuit
(3) Saw-tooth wave synchronous phase-shift firing circuit
(4) Siemens TCA785
(5) Single-phase half wave controlled rectification
(6) Single-phase half-controlled rectification bridge
(7) Single-phase full-controlled rectification/ inversion bridge
(8) 3-phase half wave controlled rectification
(9) 3-phase half-controlled rectification bridge
(10) 3-phase half wave active inversion
(11) 3-phase full-controlled rectification/ Inversion Bridge
(12) Single-phase AC voltage control
(13) 3-phase AC voltage control
(14) DC chopper circuits
(15) Thyristor(SCR)characteristics
(16) Gate-Turn-off Thyristor(GTO)characteristics
(17) Power MOSFET characteristics
(18) Giant transistor(GTR) characteristics
(19) Insulated-gate bipolar transistor(IGBT)characteristics
2. DC motor control
(1) Parameters and characteristics test of the Thyristor-controlled DC motor drive system (SCR)
(2) Tuning of the control blocks in Thyristor- controlled DC motor drive system (SCR)
(3) Non-reversible DC motor drive system with speed/current/voltage feedback (SCR)
(4) Non-reversible DC motor drive system with speed and current feedback (SCR)
(5) Reversible Thyristor-controlled DC motor drive system with non-circulating current by logic-selected firing (SCR)
3. AC motor control
(1) Variable-voltage speed control of 3-phase induction motor with current & speed control loop (SCR)
(2) Cascaded speed control of 3-phase wound-rotor induction motor with current & speed control loop (SCR)
