Rotary Vacuum Evaporator, Diagonal Condenser Manufacturer,Supplier and Exporter in China
.png)
Product Code : EL-RE-15680
Rotary Vacuum evaporator provided with LED display for R.P.M control, motorized lift arrangement for glass assembly control up to 100mm, lifting up/down through soft touch switches, digital temperature controlled water/oil bath from ambient + 5° C to 180°C, capacity 4.5 litre, geared drive unit offers smooth speed rotation from 20 to 180 R.P.M., water circulation and vacuum inlet assembly is fitted at the rear of the lift to reduce the pressure at glass joints of condenser. Diagonal double coiled condenser, pear(kjeldhal) shaped evaporating flask capacity 800ml, receiving flask capacity one liter fitted with a ball joint, feeding tube, vapour path tube, provided with rubber tube, pressure tube, seal, clips and spring a complete working unit. Patented Product.
Accessory at extra cost:
Accessory 2: Condenser double coiled with S- 35cup. with three opening for vacuum and cooling.
Accessory 3: Vapour Path tube B-24, B-29
Accessory 4: Gasket Seal for vapour tube.
Accessory 5: Gasket Seal for Special Chemicals
Accessory 6: Receiving Flask with S-35 cup (socket) joint capacity 1000ml.
Accessory 7: Evaporating Flask Kjeldhal capacity 800ml. B-24
Accessory 8: Evaporating Flask Kjeldhal capacity 500ml. B-24
Accessory 9: Evaporating Flask Kjeldhal capacity 300ml. B-24
Accessory 10: Evaporating Flask Kjeldhal capacity 100ml. B-24
Accessory 11: Tension Spring to hold condenser
Accessory 12: Standard Joint clip B-24
Accessory 13: Ball joint Clip with screw lock
Accessory 14: Glass Safety Trap
