Rotary Vacuum Evaporator, Vertical Condenser Manufacturer,Supplier and Exporter in China
.jpg)
Product Code : EL-RE-15682
Rotary vacuum evaporator provided with LED display for R.P.M control, motorized lift arrangement for glass assembly control up to 100mm, lifting up/down through soft touch switches, digital temperature controlled water/oil bath from ambient + 5° C TO 180°C, capacity 4.5 litre, geared drive unit offers smooth speed rotation from 20 to 180 R.P.M., water circulation and vacuum inlet assembly is fitted at the rear of the lift to reduce the pressure at glass joints of condenser. Vertical double coiled condenser, pear(kjeldhal) shaped evaporating flask capacity 800ml, receiving flask capacity one liter fitted with a ball joint, Feeding tube, vapour path tube, provided with rubber tube, pressure tube, seal, clips and spring a complete working unit. (Patented Product)
Accessory at extra cost:
Accessory 2: Vertical Condenser double coiled
Accessory 3: Cone adapter of condenser for vacuum
Accessory 4: Vapour path tube B-24, B-29
Accessory 5: Gasket seal for vapour tube (VITON)
Accessory 6: Gasket seal for specific chemicals
Accessory 7: Feed tube for condenser
Accessory 8: Receiving flask with S-35 cup (socket) joint capacity 1000ml.
Accessory 9: Evaporating Flask Kjeldhal capacity 800 ml. B-24
Accessory 10: Evaporating Flask Kjeldhal capacity 500 ml. B-24
Accessory 11: Evaporating Flask Kjeldhal capacity 300 ml. B-24
Accessory 12: Evaporating Flask Kjeldhal capacity 100 ml. B-24
Accessory 13: Tension Spring to hold condensor
Accessory 14: Standard Joint Clip B-24
Accessory 15: Ball joint Clip S-35 with screw lock
Accessory 16: Glass Safety Trap
