Senior Projection Microscope Manufacturer,Supplier and Exporter in China
Product Code : EL-SM-15877
Quick answer: Standard Accessories: Blue filter. Cleaning cloth and projective cover.
| Body: | Consist of 200mm diameter graduated screen 360 degree rotatable with quadruple revolving nose piece. |
| Stage: | Built in mechanical stage having low co-axial drive controls for X-Y movement with fully graduated vernier scale for manipulation of specimen slide. |
| Focussing: | Separate fine and coarse focussing using diagonally cut rack and pinion arrangement. |
| Illumination: | Workable on 220 volts AC mains with with stage micrometer slide for measuring. Built-in 12V 100W halogen bulb illuminator having highly centered filament. |
| Eyepiece: | Built in eyepiece 10X. |
| Objective: | Achromatic objective 5X, 10X, 20X and 40X SL. |
| Box: | Supplied in cardboard packing. |
Related Products
See also Dissecting Microscope, Entomological (Bull lens), Inclined Stereo Microscope, with Extension Pillar, Trinocular Research Microscope, Coaxial Focussing 30° from the same Student Microscope range.
Related Categories
Exact technical specifications, materials and certifications should be confirmed with our team before ordering. Models are updated from time to time, so please contact us for the current product datasheet.
