Single Stage Quartz Distillation Apparatus, Horizontal Model Manufacturer,Supplier and Exporter in China
.jpg)
Product Code : EL-GLE-15602
Features :
Replaceable Silica Heater : The horizontal quartz jacket is fitted with removable silica heater and screw threaded connectors for ease of cleaning.
Distillate temperature is approx. between 25º to 45º C which is ensured by an efficient condenser.
The stand is powder coated for rust free operation and lustrous appearance.
The unit automatically switches off if water level in the boiler falls below heater.
Cooling water from the condenser is re-circulated into the boiling chamber, hence saving energy.
Screw Threaded Connectors : These are provided for easy plumbing & Installation to avoid any glassware breakage during assembly.
Fuse is provided for safety in case of voltage fluctuation or short circuit.
Electrical Power : 220/240 V, 50/60Hz, Single Phase Supply.
Boiler is provided with Replaceable Constant Level Device for easy draining and cleaning of boiling chamber.
Unique Feature :
This model is equipped with in-built temperature switch to protect the Glass parts in case of water failure or overheating.
Additional Optional Accessories (At Extra Cost) :
Gate Valve : Conserves cooling water wastage in case of power failure.
Flow Switch : In-built safety feature for the equipment unit shut off in case of cooling water failure.
