High-Performance Liquid Chromatography Manufacturer,Supplier and Exporter in China
Product Code : EL-CE-13279
Quick answer: High Pressure Delivery System Specifications: Flow Range : 0.001-9.999 ml/min Delivery method : Double piston ( Main & Auxiliary) Pump head : 10m1 SST/Peek analytical Accuracy : ± 1% or ±2pLimin, whichever is greater± 1% or ± 1 pL/min, whichever is greater (Micro) Flow rate settings : 0 - 0.10 mL/min. 0.001 inc.0.10 - 0.90 mL/min.
High Pressure Delivery System Specifications:
Flow Range : 0.001-9.999 ml/min
Delivery method : Double piston ( Main & Auxiliary)
Pump head : 10m1 SST/Peek analytical
Accuracy : ± 1% or ±2pLimin, whichever is greater± 1% or ± 1 pL/min, whichever is greater (Micro)
Flow rate settings : 0 - 0.10 mL/min. 0.001 inc.0.10 - 0.90 mL/min. 0.010 inc.1.0 mL/min.+ 0.10 inc.
Precision : 0.1% RSD
Pmax : 9999 psi
System connections : 1/16" capillaries
Dimensions : 130 mm x 260 mm x 420 mm
Weight : 11 kg
Power input : 85 to 264 VAC, 47 to 63 Hz, 60 Watts
Display : 300mm
UV-VIS Spectrophotometer Detector Specifications:
Wavelength : 190-700 nm
Spectral bandwidth : 6 nm
Wavelength Accuracy : < ±1 nm
Wavelength Reproducibility : ± 0.1 nm
Flow pool volume : 8mL
Optical path : 10 mm
Dynamic Noise : -5 £± 0.75.10 AU (Methano1,1m1/min, 254nm 20,°C)
Static Noise : -5, 5± 0.5x10 AU (Empty pool, Response time 1s, 20 °C)
Dynamic Drifting : -4, 5± 1x10 AU (Methanol, 1m1/min, 254nm, 20°C)
Static Drifting : -4, 5± 0.5x10 AU (Empty pool, Response time 1s, 20 °C)
Qualitative repeatability : RSD £ 0.1%
Qualitative repeatability : RSD £ 0.5%
Dimensions : 130H x 260W x 420 D, (mm)
Weight. : 11 kg
Standard Configuration
Liquid Constant flow Pump : 2 set
UV-VIS Spectrophotometric Detector : 1 set
System Controller : 1 set
Mixer : 1 set
Injector : 1 set
