Penta Head Multi Viewing Microscope Manufacturer,Supplier and Exporter in China
Product Code : EL-BM-15862
Description :
| Body: | Equipped with four binocular head and one trinocular observation head, 0° inclined at 45° for comfortable viewing, having quadruple nosepiece. |
| Stage: | Single layer mechanical stage 140x140mm. |
| Focussing: | Standard co-axial coarse and fine focussing with fine division upto 0.002mm. |
| Illumination: | Kohler external illumination, halogen lamp 12V/50W. |
| Eyepiece: | Wide Field 10X, 5 Pairs. |
| Objective: | Plan objective (infinity corrected) PL 4X, PL 10X, PL 40X and PL 100X. |
| Condenser: | Condenser N.A.1.25 with iris diaphragm and filter. |
| Pointer: | The built in LED green light pointer, with adjustable brightness can be moved in the field of view during group discussion. |
| Box: | Supplied in thermocol packing. |
| Optional Accessories: Trinocular head Eyepieces: Wide Field 16X, Wide Field 20X, P16X Semi-plan Objective: 20X, 60X SL Plan Objective: 20X, 60X SL Microscopy camera eyepiece |
