SCARA Manufacturer,Supplier and Exporter in China
Product Code : EL-MELE-12977
Quick answer: The SCARA is manufactured by Science Lab Supplies, a China-based exporter of mechanical engineering lab equipment and trainer kits, and forms part of the Mechanical Engineering Lab Equipment catalogue used by engineering colleges and polytechnics in mechanical engineering laboratories.
|
Type |
SCARA |
|||
|
Number of Axes |
4 |
|||
|
Arm Length (mm) |
300 |
500 |
||
|
Axis Specs |
X Axis |
Arm length (mm) |
100 |
300 |
|
Rotation Range (deg) |
+/-127 |
|||
|
Y Axis |
Arm length (mm) |
200 |
||
|
Rotation Range (deg) |
+/- 142 |
|||
|
Z Axis |
Route (mm) |
150 |
||
|
R |
Rotation Range (deg) |
+/- 360 |
||
|
Highest Speed |
X (deg/sec) |
600 |
||
|
|
Y (deg/sec) |
600 |
||
|
X,Y Synthesis (m/s) |
5.2 |
7.3 |
||
|
Z (m/s) |
1.3 |
|||
|
R (deg/sec) |
1667 |
|||
|
Standard Cycle Time (seconds) |
0.5 |
0.48 |
||
|
Repeat positioning accuracy |
X,Y axis (mm) |
+/- 0.01 |
||
|
|
Z (mm) |
+/- 0.01 |
||
|
|
R (deg) |
+/- 0.005 |
||
|
Rated / Max load (kg) |
2 kg/ 5 kg |
|||
|
R-axis allows load moment of inertia (Rated/ max) kg.m2 |
0.005 |
|||
|
User Signal line |
"0.2 x 16 lines |
|||
|
8 outputs |
||||
|
|
