3 5/6 6000 Counts Trms Auto-ranging Multimeter with Temperature, Capacitance, Frequency, Duty Cycle, Data Hold, Back Light, hFE Test, Max Hold, Relativity Manufacturer,Supplier and Exporter in China
Product Code : EL-TAME-13368
Quick answer: The 3 5/6 6000 Counts Trms Auto-ranging Multimeter with Temperature, Capacitance, Frequency, Duty Cycle, Data Hold, Back Light, hFE Test, Max Hold, Relativity is manufactured by Science Lab Supplies, a China-based exporter of test and measurement instruments for engineering laboratories, and forms part of the Test and Measurement Equipment catalogue used by engineering colleges and technical institutes in engineering test and measurement laboratories. 3 5/6 digit 6000 counts Trms LCD Display Auto Ranging, Data Hold, APO, Relative, Temperature, Frequency, Capacitance Diode, Continuity, Resis-tance Check In engineering test and measurement laboratories, the 3 5/6 6000 Counts Trms Auto-ranging Multimeter with Temperature, Capacitance, Frequency, Duty Cycle, Data Hold, Back Light, hFE Test, Max Hold, Relativity is typically used for structured demonstrations and student practicals, giving engineering departments a reliable tool for repeatable results.
3 5/6 digit 6000 counts Trms LCD Display Auto Ranging, Data Hold, APO, Relative, Temperature, Frequency, Capacitance Diode, Continuity, Resis-tance Check
|
Ranges |
|
|
DC Voltage |
600mV/6V/60V/600V/1000V |
|
Accuracy |
± (0.8%+5dgts) on 600mV |
|
|
± (0.8%+3dgts) on 6V - 600V |
|
|
± (0.8%+5dgts) on 1000V |
|
AC Voltage |
600mV/6V/60V/600V/750V |
|
Accuracy |
± (1.2%+8dgts) on 600mV |
|
|
± (1.2%+6dgts) on 6V-600V |
|
|
± (1.2%+8dgts) on 750V |
|
DC Current |
600µA / 6000µA / 60mA / |
|
|
600mA / 6A / 10A (Fused) |
|
Accuracy |
± (0.8%+5dgts) on 600µ-600mA |
|
|
± (1.5%+5dgts) on 6A-10A |
|
AC Current |
600µA / 6000µA / 60mA / |
|
|
600mA / 6A / 10A (Fused) |
|
Accuracy |
±(1.5%+8dgts) on 600µ-600mA |
|
|
± (2.0%+10dgts) on 6A-10A |
|
Resistance |
600Ω/6KΩ/60KΩ/600KΩ/ |
|
|
6MΩ/60MΩ |
|
Accuracy |
± (1.5%+5gts) on all ranges |
|
Capacitance |
60nF/600nF/6µF/60µF/ |
|
|
600µF/20µF |
|
Accuracy |
± (8.0%+5gts) on all ranges |
|
Frequency |
60MHz (Auto-Ranging) |
|
Accuracy |
±(1.0%+5dgts) on all ranges |
|
Temperature |
-40°C ~ 1370°C |
|
Accuracy |
± (2%+2dgt) on all ranges |
|
Power |
9V Battery, NEDA 6F22 Type |
|
Low Battery |
Battery Icon is indicated |
|
Dimensions |
190 x 90 x 35mm (approx.) |
|
Weight |
360gms. Incl. Battery (approx.) |
|
Accessories |
Test Leads, Carrying Case |
|
|
Operational Manual |
|
|
K-Type Thermocouple Leads |
