CNC Turning Center X- axis travel 130 mm and Z - axis Travel 400mm, Chuck size - 200mm Manufacturer,Supplier and Exporter in China

CNC Turning Center X- axis travel 130 mm and Z - axis Travel 400mm, Chuck size - 200mm

Product Code : EL-MELE-12973

CNC Turning Centre Lathe with Industrial control, Electrical Control Box, Central Automatic Lubrication System, LM Guides for X & Z Axes, 8 Station Programmable Turret, Flood Coolant System, hydraulic Chuck, hydraulic tailstock

  • The turning center is a 2 axis production machine with 8 station programmable turret.
  • The machine is built on casted base and bed and offered with industrial CNC control tank
  • It is offered with industrial CNC control system, Siemens/ Fanuc
  • Other features include dynamically calibrated cartridge spindle, hydraulic Chuck and manual tailstock, removable chip tray.
  • It comes automatic lubrication system and adjustable flood coolant system



Objective
Understand the concept, components of advanced industrial machine and learn about the advanced Fanuc/Siemens/Syntec controller handling & programming skills for a turning machine to produce different kinds of components with optimized cycles and execute different kinds of practical applications simulated as exercises.



Learning Objectives:
Having successfully completed this lab, the student will demonstrate knowledge in –

  1. Learn about techniques to optimize the cutting parameters
  2. Advanced programming techniques matching industrial standards.
  3. Advanced machining cycles & control techniques.
  4. Knowledge on centralized Lubrication and re-circulating coolant system
  5. Learn about Intricate Tool changers system.
  6. Maintenance of CNC machineries and Trouble shooting


Training Skills –

  1. Convenient operation and Learn about advanced programming
  2. Identification of the Components of the CNC System
  3. User friendly and graphically assisted different canned cycles
  4. Discussion on Programming Elements
  5. Discussion on Industry Standard ISO G and M Codes
  6. Discussion on Various Tools to be used in a CNC Turning Operation
  7. Study on Process Planning
  8. Discussion on Program Zero and Offset definition
  9. Preparation of CNC Programs using CNC Turning Machines
  10. Discussion on Various Machining Cycles used in CNC Turning Programming
  11. General Maintenancs



Machine dimensions

  • Dimensions L x W x H : 2200 x 1860 x 1900mm
  • Weight (approx) : 2650kg



SPECIFICATIONS

Axes

X- axis travel

mm

130

Z - axis Travel

mm

400

Programmable feed rate

mm/min

0-10000

Rapid feed rate

mm/min

30000

Axis motor X / Z Type



AC SERVO MOTOR

Slides



Linear Motion Guide ways

CAPACITY

Chuck size (Manual/ Hydraulic)

mm

200

Chuck Type



Hydraulic

Maximum turning Diameter

mm

225

Maximum turning Length

mm

350

Bed

type

45 deg Slant bed

No. of axes

no

2

Swing over cross slide

mm

160

Swing over bed

mm

528

Distance between centers

mm

410

ACCURACY

Positioning Accuracy

mm

0.01
