Monocular Research Microscope, Basic Manufacturer,Supplier and Exporter in China
Product Code : EL-SM-15837
Description :
| Body: | 45 degrees inclined monocular head rotatable through 360 degrees. Quadruple nose piece with accurate centering and positive click stops. |
| Stage: | Mechanical stage of 120x140mm. X-Y movement with fully graduated vernier scale for manipulation of specimen slide. |
| Focussing: | Separate fine and coarse focussing using diagonally cut rack and pinion arrangement. |
| Illumination: | 6V-20W halogen lamp, operating on 220/110 Volts. |
| Condenser: | Two lens Abbe condenser N.A. 1.25 with filter support, movable by rack & pinion arrangement. |
| Eyepiece: | Wide Field 10X and either of Huygenian 5X or 15X. |
| Objective: | Achromatic JIS Standard 36mm 4X, 10X, 40X SL and 100X SL oil immersion |
| Box: | Supplied in a plywood box with essential accessories. |
Related Products
See also Dissecting Microscope, Entomological (Bull lens), Inclined Stereo Microscope, with Extension Pillar, Trinocular Research Microscope, Coaxial Focussing 30° from the same Student Microscope range.
Related Categories
Exact technical specifications, materials and certifications should be confirmed with our team before ordering. Models are updated from time to time, so please contact us for the current product datasheet.
